對於圖像輪播框架的實現，網上有很多種方法，可以使用UIScrollView,也可以使用UICollectionView。

今天就撸一波代碼，打算使用3個UIImageView實現，這樣比較節省內存（個人偏向於這個方案），當然由於UICollectionView的Cell有復用機制，也比較好。

思路：1)在UIScrollView上面添加3個UIImageView，分別為leftImageView,centerImageView,RightImageView

2)UIScrollView初始化時，contentOffset停留在中間的UIImageView

3)使用一個定時器，定時器觸發是，把contentOffset從中間通過動畫滑動到第三個UIImageView的位置

4)滑動完成時候，要進行最關鍵的復位操作，就是迅速把contentOffset切換回第二個UIImageView的位置，但是切換前，先centerImageView.image = rightjImageView.image,注意，這裡不適用動畫，所以用戶看不出來切換了

5）下次定時器觸發時，又把contentOffset從第二個位置通過動畫滑動到第三個位置

6）事實上2個UIImageView就可以實現，但是左邊一直有一個提供用戶手動向左滑動



不費話了，貼代碼：

頭文件：

//
//  CHRDanTangHeaderScrollView.h
//  test
//
//  Created by Chen Heren on 16/10/12.
//  Copyright (c) 2016年 Chen Heren. All rights reserved.
//

#import

@class CHRDanTangHeaderScrollView;

@protocol CHRDanTangHeaderScrollViewDelegate

-(void)DanTangHeaderScrollView:(CHRDanTangHeaderScrollView *)scrollView selectedAt:(NSInteger)index;

@end

@interface CHRDanTangHeaderScrollView : UIView

@property (strong, nonatomic) NSArray *imageUrls;

@property (nonatomic) CGFloat intervalTime;

@property (weak, nonatomic) id delegate;

-(instancetype)initWithFrame:(CGRect)frame ImageUrls:(NSArray *)imageUrls IntervalTime:(CGFloat)intervalTime;

@end



源文件：



//
//  CHRDanTangHeaderScrollView.m
//  采用3個UIImageView實現循環顯示
//  思路：暗渡陳倉
//  定時器Fire時，正常進行滑動，待滑動完成，重新把視圖contentoffset恢復到中間uiimageview的狀態
//  Created by Chen Heren on 16/10/12.
//  Copyright (c) 2016年 Chen Heren. All rights reserved.
//

#import "CHRDanTangHeaderScrollView.h"
#import "UIImageView+WebCache.h"


@interface CHRDanTangHeaderScrollView ()

///滑動視圖
@property (strong, nonatomic) UIScrollView *scrollView;
///指示器
@property (strong, nonatomic) UIPageControl *pageControl;
///左UIImageView
@property (strong, nonatomic) UIImageView *leftImageView;
///中間UIImageView
@property (strong, nonatomic) UIImageView *centerImageView;
///右UIImageView
@property (strong, nonatomic) UIImageView *rightImageView;

@property (nonatomic) NSInteger currentPage;

@property (strong, nonatomic) NSTimer *timer;

@end

@implementation CHRDanTangHeaderScrollView


-(instancetype)initWithFrame:(CGRect)frame ImageUrls:(NSArray *)imageUrls IntervalTime:(CGFloat)intervalTime{
    self = [self initWithFrame:frame];
    if (self) {
        self.imageUrls = [NSArray arrayWithArray:imageUrls];
        self.intervalTime = intervalTime;
        self.currentPage = 0;
        [self setupUI];
    }
    return self;
}

-(void)setupUI{

    [self addSubview:self.scrollView];
    [self addSubview:self.pageControl];
    [self setupImageView];
    [self setupTimer];
}

-(UIScrollView *)scrollView{
    if (_scrollView == nil) {
        _scrollView = [[UIScrollView alloc]initWithFrame:self.bounds];
        _scrollView.contentSize = CGSizeMake(CGRectGetWidth(self.scrollView.frame) * 3, CGRectGetHeight(self.scrollView.frame));
        _scrollView.contentInset = UIEdgeInsetsMake(0, 0, 0, 0);
        _scrollView.delegate = self;
        _scrollView.pagingEnabled = YES;
        _scrollView.showsHorizontalScrollIndicator = NO;
        _scrollView.decelerationRate = 1.0;
        _scrollView.contentOffset = CGPointMake(CGRectGetWidth(self.scrollView.frame), 0);
    }
    return _scrollView;
}

-(UIPageControl *)pageControl{
    if (_pageControl == nil) {
        _pageControl = [[UIPageControl alloc]initWithFrame:CGRectMake(self.frame.size.width/2-50, self.frame.size.height-35, 100, 30)];
        _pageControl.numberOfPages = self.imageUrls.count;
        _pageControl.currentPageIndicatorTintColor = [UIColor whiteColor];
        _pageControl.pageIndicatorTintColor = [UIColor lightGrayColor];
    }
    return _pageControl;
}

-(void)setupImageView{

    self.leftImageView = [[UIImageView alloc]initWithFrame:CGRectMake(self.frame.size.width *0, 0, self.frame.size.width, self.frame.size.height)];
    self.centerImageView = [[UIImageView alloc]initWithFrame:CGRectMake(self.frame.size.width *1, 0, self.frame.size.width, self.frame.size.height)];
    self.rightImageView = [[UIImageView alloc]initWithFrame:CGRectMake(self.frame.size.width *2, 0, self.frame.size.width, self.frame.size.height)];

    [self.leftImageView sd_setImageWithURL:[self getImageUrlBeforeIndex:self.currentPage]];
    [self.centerImageView sd_setImageWithURL:[self getImageUrlAtIndex:self.currentPage]];
    [self.rightImageView sd_setImageWithURL:[self getImageUrlAfterIndex:self.currentPage]];

    self.leftImageView.contentMode = UIViewContentModeScaleAspectFit;
    self.centerImageView.contentMode = UIViewContentModeScaleAspectFit;
    self.rightImageView.contentMode = UIViewContentModeScaleAspectFit;

    ///用戶看到的只有中間視圖，所以為了簡單起見，只需要添加中間視圖的點擊響應
    UITapGestureRecognizer *tap = [[UITapGestureRecognizer alloc]initWithTarget:self action:@selector(imageViewTap)];
    self.centerImageView.userInteractionEnabled =  YES;
    [self.centerImageView addGestureRecognizer:tap];


    [self.scrollView addSubview:self.leftImageView];
    [self.scrollView addSubview:self.centerImageView];
    [self.scrollView addSubview:self.rightImageView];

}

-(void)setupTimer{
    self.timer = [NSTimer timerWithTimeInterval:self.intervalTime target:self selector:@selector(timerTick) userInfo:nil repeats:YES];
    [[NSRunLoop mainRunLoop]addTimer:_timer forMode:NSRunLoopCommonModes];
}


-(void)timerTick{
    self.currentPage++;
    if (self.currentPage == self.imageUrls.count) {
        self.currentPage = 0;
    }
    ///此處設置動畫的時間一定要小於滑動的時間
    [UIView animateWithDuration:1 animations:^{
        ///動畫發生的滑動
        self.centerImageView.userInteractionEnabled =NO;
        self.scrollView.contentOffset =CGPointMake(CGRectGetWidth(self.scrollView.frame) * 2, 0);
    } completion:^(BOOL finished) {
        ///滑動完成後，把當前現實的imageview重現移動回中間位置，此處不能使用動畫，用戶感覺不到
        ///移動前,先把中間imageview的image設置成當前現實的iamge
        self.centerImageView.userInteractionEnabled = YES;
        self.leftImageView.image = self.centerImageView.image;
        self.centerImageView.image = self.rightImageView.image;
        self.scrollView.contentOffset =CGPointMake(CGRectGetWidth(self.scrollView.frame) * 1, 0);
        [self.rightImageView sd_setImageWithURL:[self getImageUrlAfterIndex:self.currentPage]];
        self.pageControl.currentPage = self.currentPage;
    }];


}

#pragma mark - 用戶點擊

-(void)imageViewTap{
    NSLog(@"tap at :%ld",self.currentPage);
    [self.delegate DanTangHeaderScrollView:self selectedAt:self.currentPage];
}

#pragma mark - 循環獲取URL

-(NSURL *)getImageUrlBeforeIndex:(NSInteger)index{
    if (index == 0) {
        return [self.imageUrls lastObject];
    }else{
        return self.imageUrls[index-1];
    }
}

-(NSURL *)getImageUrlAfterIndex:(NSInteger)index{
    if (index == (self.imageUrls.count - 1)) {
        return [self.imageUrls firstObject];
    }else{
        return self.imageUrls[index+1];
    }
}

-(NSURL *)getImageUrlAtIndex:(NSInteger)index{
    if (index<0 || index >= self.imageUrls.count) {
        return nil;
    }else{
        return self.imageUrls[index];
    }
}

#pragma mark - scrollView滑動事件

-(void)scrollViewWillBeginDragging:(UIScrollView *)scrollView{
    ///有用戶手動拖動，則停止定時器
    [self.timer invalidate];
}

-(void)scrollViewDidEndDragging:(UIScrollView *)scrollView willDecelerate:(BOOL)decelerate{
    ///用戶滑動停止，重新啟動定時器
    [self setupTimer];
}

-(void)scrollViewDidEndDecelerating:(UIScrollView *)scrollView{
    NSInteger index = scrollView.contentOffset.x/scrollView.frame.size.width;
    if (index ==0) {
        //向左滑動
        self.currentPage--;
        if (self.currentPage <0 ) {
            self.currentPage = self.imageUrls.count;
        }
        self.rightImageView.image = self.centerImageView.image;
        self.centerImageView.image = self.leftImageView.image;
        scrollView.contentOffset = CGPointMake(CGRectGetWidth(self.scrollView.frame) * 1, 0);
        [self.leftImageView sd_setImageWithURL:[self getImageUrlBeforeIndex:self.currentPage]];
         self.pageControl.currentPage = self.currentPage;
    }else if(index == 2){
        ///向右滑動
        self.currentPage++;
        if (self.currentPage ==self.imageUrls.count ) {
            self.currentPage = 0;
        }
        self.leftImageView.image = self.centerImageView.image;
        self.centerImageView.image = self.rightImageView.image;
        scrollView.contentOffset = CGPointMake(CGRectGetWidth(self.scrollView.frame) * 1, 0);
        [self.rightImageView sd_setImageWithURL:[self getImageUrlAfterIndex:self.currentPage]];
         self.pageControl.currentPage = self.currentPage;
    }
    ///沒有滑動一頁
}




@end

使用：

#import "ViewController.h"
#import  "CHRDanTangHeaderScrollView.h"

@interface ViewController ()

@end

@implementation ViewController

- (void)viewDidLoad {
    [super viewDidLoad];
    // Do any additional setup after loading the view, typically from a nib.
    NSURL *url = [[NSBundle mainBundle]URLForResource:@"1" withExtension:@".png"];
    NSURL *ur2 = [[NSBundle mainBundle]URLForResource:@"2" withExtension:@".png"];
    NSURL *ur3 = [[NSBundle mainBundle]URLForResource:@"3" withExtension:@".png"];
    NSURL *ur4 = [[NSBundle mainBundle]URLForResource:@"4" withExtension:@".png"];
    CHRDanTangHeaderScrollView *scrollView = [[CHRDanTangHeaderScrollView alloc]initWithFrame:CGRectMake(0, 100, self.view.frame.size.width, 200) ImageUrls:@[url,ur2,ur3,ur4] IntervalTime:2];
    scrollView.delegate = self;
    [self.view addSubview:scrollView];

}


-(void)DanTangHeaderScrollView:(CHRDanTangHeaderScrollView *)scrollView selectedAt:(NSInteger)index{
    NSLog(@"%ld",index);
}

@end





demo傳送門：https://git.oschina.net/heren/CHRScrollView.git
